The BI9108GM24F4T-60WS is a 10G uplink L3 managed industrial Ethernet fiber switch. It has 8*10/100/1000Base-T RJ45 ports and 24*100/1000M SFP fiber slot ports and 4*1/10G SFP+ fiber slot ports. Each port can support wire-speed forwarding. The BI9108GM24F4T-60WS has L3 full network management function, supports IPV4/IPV6 management, supports static route full line rate forwarding, supports complete security protection mechanism, complete ACL/QoS policy and rich VLAN functions, and is easy to manage and maintain. Supports multiple network redundancy protocols STP/RSTP/MSTP (<50ms) and (ITU-T G.8032) ERPS (<20ms) to improve link backup and network reliability. When one-way network fails, communication can be quickly restored to ensure important uninterrupted communication for applications. According to the actual application requirements, you can configure multiple application services such as port traffic control, VLAN division, and SNMP through the Web network management mode. It meets the needs of various industrial Ethernet application environments and is suitable for industrial, intelligent transportation, rail transit, power industry, mining, petroleum, marine, metallurgical and green energy construction to form a cost-effective, stable and reliable communication network.
High-performance Gigabit and 10G network switches for enterprise and industrial applications
Reliable PoE solutions for IP cameras, wireless access points, and smart network devices
Advanced Layer 2 and Layer 3 managed switches with VLAN, QoS, and security features
Industrial-grade switches designed for harsh environments with stable performance
Seamless fiber connectivity with media converters and SFP transceivers for long-distance networking
Efficient network management tools with monitoring, diagnostics, and secure remote access
Gigabit multi fiber port access with 10G uplink support. All series support Gigabit Ethernet port + Gigabit SFP port + 10G SFP+ uplink combination, enabling flexible networking for various scenarios. Supports non-blocking wire-speed forwarding and full-duplex (IEEE802.3x) as well as half-duplex based on backpressure.
| Model | BI9108GM24F4T-60WS |
| Interface Characteristics | |
| Fixed Port |
24 × 10/100/1000Base-T RJ45 ports + 4 × 10G SFP+ uplink ports Supports Gigabit Ethernet + SFP + 10G SFP+ combination |
| Ethernet Port |
Supports auto-negotiation (10/100/1000Mbps) Full/half duplex, MDI/MDI-X auto adaptation |
| Twisted Pair Transmission | CAT5/CAT5e/CAT6 cable transmission up to 100m |
| Optical Fiber Port |
Gigabit SFP fiber interface, supports multiple fiber modules Transmission distance depends on module type |
| SFP Port Distance | Depends on SFP module (multi-mode / single-mode) |
| Chip Parameter | |
| Management Type | L3 Managed |
| Network Protocol | IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3ae |
| Switching Capacity | 256Gbps non-blocking |
| Forwarding Rate | 190Mpps |
| MAC Address | 32K |
| Buffer Memory | 4MB |
| Jumbo Frame | 9KB |
| LED Indicator | Power, System, Link/Act indicators |
| Reset Switch | Yes (factory reset support) |
| Power | |
| Power Input | AC 100–240V |
| Power Supply | Built-in power supply |
| Power Consumption | ≤ 60W |
| Physical Parameter | |
| Operating Temperature | -10°C to 55°C |
| Storage Temperature | -40°C to 75°C |
| Dimensions | 440 × 260 × 44 mm |
| Weight | Approx. 3.5kg |
| Certification & Warranty | |
| Certification | CCC, CE, FCC, RoHS |
| Warranty | 5 Years |
| Network Management Features | |
| VLAN | 4K VLAN, Voice VLAN, QinQ |
| QoS | SP, WRR, SP+WRR scheduling, DSCP priority |
| Security | 802.1X, ACL, port isolation, storm control |
| Management | Web UI, CLI (Console/Telnet), SNMP (V1/V2/V3), RMON |
